Siemens SINUMERIK 840C Installation Instructions

7 Drive Machine Data (SIMODRIVE Drive MD) 04.96
7.4.3 Diagnosis/service MD (data description - as from SW 3)
Position actual value
12000
Default value Lower output limit Upper output limit Units
– -99999999 99999999 –
Active
at once
Output of currently valid position actual value which is dependent on the position control for
rotary axes (NC-MD 5640.5) and position control resolution (NC-MD 18000.0-3). The
information is output in the drive service displays.
v-max (FDD)/n-setpoint max (MSD) (as from SW 4)
12001
Default value Lower output limit Upper output limit Units
– – – –
Active
Position controller cycle (as from SW 4)
12002
Default value Lower output limit Upper output limit Units
– – – –
Active
Actual gear stage (as from SW 4)
12003
Default value Lower output limit Upper output limit Units
– – – –
Active
7–176 © Siemens AG 1992 All Rights Reserved 6FC5197- AA50
SINUMERIK 840C (IA)
