11 Data Backup/CPU Replacement 01.99
11.1.3 Saving/loading NCK data
Procedure to save all RAM data on hard disk
Use file names (not for MPF and SPF) and SK ”OK” to save
MPF, SPF, TOA, SEA, ZOA and RPA data
(without IKA) (take note of channel No.)
Startup
Diagnosis operating area
Machine data
Input window must appear at bottom
Diagnosis operating area
(TEA1 to TEA4, IKA1 to IKA3
are being saved)
Use SK ”Save on hard disk”
to save all MD under a new file name
File functions
SK "Save PLC"
Query: Overwrite? Yes/No
(if available)
END
General reset mode
Select the PLC/programs directory
Copy file USER_PROG to the archive
and rename it
Services and data management operating areas
Set password, e.g. 1111
a
a
a
Start
Diagnosis operating area
Programming operating area
SK "NC"
SK "Save start"
Place cursor on newly created workpiece
Use ”Select” key to choose data type
Place cursor on NC/data directory
Use ”Select” key to choose GIA
Create a new workpiece in the local
or global directory
Services operating area
SK "Save start"
By using file name and SK ”OK” data are being saved
Note:
When implementing tool management the data blocks used must be saved by PG.
