06.93 12 Functional Descriptions

12.1.2 Functional description

Because compensation is not possible at the reference point, the error curve must be shifted

so that the error is zero at the reference point.

Error=0

Traverse

path

Pos.

error

Spacing

Reference point

Neg.

error
