Air gaps and
creepage distan‐
ces
IEC 61131-2:2017
IEC 61010-1:2016
UL 61010-2-201:2018
CSA C22.2, No. 142
Overvoltage category II
Pollution degree 2
Isolation stability IEC 61131-2:2017
CSA C22.2, No. 142
UL 61010-2-201:2018
Ethernet port:
1 500 V AC
Other electrical circuits:
Test voltage:
500 V AC or 707 V DC
Use in hazard‐
ous
areas
IEC 60079-0:2017
IEC 60079-15:2016
When using the electronic weighing system in a hazardous area, ob‐
serve the ATEX/IECx special conditions for use (Page 17).
Electromagnetic
compatibility
IEC 61000-6-2:2016
IEC 61000-6-4:2018
All shielded cables must be grounded at both ends to comply with the
requirements for electromagnetic compatibility.
If the shielded cable is routed out of the hazardous area for explosion-
proof equipment, both ends of the cable shield must be connected to the
potential equalization.
To comply with the requirements for lightning strikes, additional meas‐
ures are required (see footnote Table 12-14) for installation in Zone A
according to IEC 61131-2.
Electromagnetic
compatibility
Interference
emission in in‐
dustrial area in
accordance with
EN 61000‑6‑4
Emission of ra‐
dio interference
(interference
field strength)
Class A industrial environment:
IEC 61000-6-4: 2018
IEC/CISPR 16-2-3: 2008
EN55016-2-3:2006
30 ... 230 MHz, 40 dBμV/m Q
230 ... 1000 MHz, 47 dBμV/m Q
1 ... 3 GHz / 76 dBμV/m
peak, 56 dBμV/m average
3 ... 6 GHz / 80 dBμV/m
Emission on
power supply ca‐
bles
Class A: Industrial environment:
IEC 61000-6-4: 2018
IEC/CISPR 16-2-1:2010
EN 55016-2-1: 2009
Class A: Industrial environment
0.15 ... 0.5 MHz, 79 dBμV Q
0.15 ... 0.5 MHz, 66 dBμV M
0.5 ... 30 MHz, 73 dBμV Q
0.5 ... 30 MHz, 60 dBμV M
Emission con‐
ducted Ethernet
EN 61000-6-4:2018
IEC/CISPR 22: 2008
EN55022: 2010
0.15 ... 0.5 MHz:
53 ... 43 dBμV Q
40 ... 30 dBμV M
0.5 ... 30 MHz:
43 dBμV Q / 30 dBμV M
Technical data
10.10 Electrical, EMC and climatic requirements
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 155
