Article number 7MH4138-6BA00-0CU0
Interference im‐
munity in indus‐
trial area in ac‐
cordance with
EN 61000-6-2
Burst pulses on
power supply ca‐
bles
EN 61000-4-4:2004
EN 45501:2015
OIML R 76:2006
NAMUR NE21:2011
EN 61326-1:2006
EN 61131-2:2017
±1.0 kV / ±2.0 kV 5/50 ns/5 kHz
Burst pulses on
data and signal
cables
±2.0 kV 5/50 ns/5 kHz
Electrostatic dis‐
charge (ESD)
EN 61000-4-2:2009
EN 45501:2015
OIML R 76:2006
NAMUR NE21:2011
EN 61131-2:2017
2, 4, 6 kV direct/indirect
Electrostatic air
discharge (ESD)
2, 4, 6, 8 kV
Surge on power
supply cables
IEC 61131-2 :2017
NAMUR NE21 :2011
OIML R76 -2:2006
EN 61000-4-5 :2015
EN 45501:2015
±1.0 kV line to line
±2.0 kV line to earth
Power supply lines:
±0.5 kV line to line
±1.0 kV line to earth
±2.0 kV line to earth & line to line
1)
Surge on data
and signal ca‐
bles shielded
±2.0 kV shield to ground
Surge on data
and signal ca‐
bles unshielded
0.5 kV / 2 kV
2)
Electromagnetic
RF fields
IEC 61131-2 :2017
NAMUR NE21 :2011
OIML R76-2 :2006
EN 61000-4-3:2011
EN 45501:2015
80 MHz ... 6 GHz: 10 V/m
Induced conduc‐
ted interference
IEC 61131-2 :2017
NAMUR NE21 :2011
OIML R76-2 :2006
EN 61000-4-6 :2015
10 kHz ... 80 MHz: 10 V
rms
1)
An external fuse must be provided to comply with the requirement (e.g. Lightning conductor BVTAD24, Dehn & Söhne
company)
2)
An external fuse must be provided to comply with the requirement (e.g. Lightning conductor BSPM4BE24, Dehn & Söhne
company)
Technical data
10.10 Electrical, EMC and climatic requirements
Technology module TM SIWAREX WP351 HF
156 Operating Instructions, 01/2020, A5E47521010-AA
