Supply voltage L+/M
With a dark BaseUnit, the supply voltage of the left BaseUnit is used.
The electronic weighing system monitors whether the supply voltage is connected.
Load cell connection
In case of 6-wire load cells, the supply voltage is measured over the terminals 1 (SEN+) and 7
(SEN-) and used as reference. A voltage drop on the load cell cable does not have an effect on
the measurement.
You can connect 4-wire as well as 6-wire load cells. The electronic weighing system is set for
operation with 6-wire load cells in the factory.
If the power of the electronic weighing system-internal power supply of the load cells is not
sufficient, use an external power supply source to supply the load cells.
Note
Compensate for interferences when connecting 4-wire load cells
If you use 4-wire load cells, we recommend that you use a 6-wire cable between the electronic
weighing system and the terminal box.
● Set a wire jumper in the terminal box between EXC+/SEN+ and EXC-/SEN-.
The wire jumper compensates for interferences between the electronic weighing system
and the terminal box.
Connecting
4.2 Connection to electronic weighing system
Technology module TM SIWAREX WP351 HF
Operating Instructions, 01/2020, A5E47521010-AA 25
