Check if entrance sensor works properly (Diagnosis Mode)
If it does not operate, replace the sensor and test again
It occurs when paper does not reach at the entrance sensor within a certain
time after pick up attempt from MPT
(Even if 102 paper jam occurs when pickup from MPT fails, there may not be a
jammed paper on the paper path)
- Check if papers are loaded properly (check feeder guide’s status)
- Check if there are too many papers in the tray
- Check the paper status (check if paper is damaged or not)
- Check if there’s an obstacle between the tray and entrance sensor’s
paper path
- Check if the pickup solenoid operates properly picks up
- If it does not operate, replace the solenoid and test again
- Check if entrance sensor works properly (Diagnosis Mode)
- If it does not operate, replace the sensor and test again
It occurs when paper’s top does not reach at the delivery sensor within a
certain time after passing the entrance sensor
1. Check if there’s an obstacle between the entrance sensor and delivery
sensor’s paper path
2. Check if delivery sensor works properly (Diagnosis Mode)
3. If it does not operate, replace the sensor and test again
It occurs when paper’s bottom does not get out entrance sensor within a
certain time
1. Check if there’s an obstacle on paper delivery path after the delivery
sensor
2. Check if entrance sensor works properly (Diagnosis Mode)
3. If it does not operate, replace the sensor and test again
It occurs when paper’s bottom does not get out the delivery sensor within a
certain time
1. Check if there’s an obstacle on paper delivery path after the delivery
sensor
2. Check if delivery sensor works properly (Diagnosis Mode)
3. If it does not operate, replace the sensor and test again
