11. System configuration
Pump settings => Pump settings =>Temperature Control => Internal Sensor
Step Key Display Description
Temperature Control
Set internal sensor (controller board) or external sensor
7
• Press <OK control key>
)You will enter the Temperature Settings menu
The following settings are available:
o Internal Sensor/External Sensor
o Temperature Limits
7.1
• Press <Select control key>
• Use <down/up arrow key> to select Internal Sensor
• Press <OK control key>
• Press <Select control key>
• Use <down/up arrow key> to select disabled/enabled
If enabled:
)The new menu item IO Board [1] is for information only and the assignment cannot be
changed.
• Press <Save control key>
• Press <Back control key>
Temperature Control
Int. Sensor Setting
Exter. Sensor Setting
Temperature Limits
Temperature Control
Int.Sensor
[active]
IO Board
[1]
SelectBack
Select
