Smartrise F220

101
TRACTION DZ1/DZ2 MAGNET PLACEMENT – ALL
LANDINGS
Set the DZ magnet on the left
side of the tape holes. Place the
paper jig on the tape and align
the magnet against the jig.
Step 2
Step 4
Step 3
Step 5
8.5”
DZ1
DZ2
LEV
14 12 10
8 6 4
LEV
14
12
10
8
6
4
