GOVERNOR ENCODER LANDING SYSTEM INSTALLATION
Introduction
Tapeless Landing System Mount
Install the fixture on top of the car so that the Blue Guide wheels
are on both sides of the center of the guide rail. There are 4
mounting brackets supplied for easy installation and removal.
The fixture should be
mounted so that the outer
edge of the guide wheels
(flat side) run along the
outer edge of the center
guide rail.
When installed correctly, a flat edge can be placed across both
guide wheels and the narrow face of the guide rail and should
make contact with all three surfaces.
