Hydros/Low Speed Traction Cars – Use the ETS
Hoistway Switch Positioning Table on the next
page for proper distance.
High Speed Traction Cars – Use the “Slide
Distance – Determining ETS Magnet Placement”
procedure for proper distance.
HYDRO’s ONLY
When installing the DT1 magnet: For low
speed cars make sure the DT1 magnet
has a min gap of 4” from bottom of DT1
magnet to Top of DZ Magnet.
