ADJUSTMENT TOO HIGH/TOO LOW METHOD
** CAN ONLY BE DONE FROM THE CT or COP SRU BOARDS **
NOTE: BE SURE RELEVELING IS TURNED OFF BEFORE
ATTEMPTING TO ADJUST THE FLOOR LEVELS.
Navigate to MAIN MENU | SETUP | FLOOR LEVELS | RELEVELING and set it to
“NO”. Make sure to turn it back on after all floor levels have been set.
Bottom Floor
1. Send the car on a call down to the bottom floor.
2. When the car stops, see if it is level with the landing floor.
3. If the car is level you are finished adjusting this floor.
4. If the car is not level, navigate to the MAIN MENU | SETUP | FLOOR LEVELS
| TOO HIGH/TOO LOW screen.
5. Use the up and down arrow keys to specify how high or low the car is relative
to the landing. Save the value. Be sure the car does not leave the bottom
floor until the value has finished saving or that value may get applied to the
next floor the car stops at.
6. Send the car to an upper floor then back down to the bottom floor.
7. If the car stops level with the floor you are now finished adjusting the bottom
floor. If not, repeat steps 1-6.
Intermediate Floors
1. Start with the car below the target floor (the floor you wish to adjust).
2. Send the car on a call up to the target floor.
3. When the car stops, see if it is level with the landing floor.
4. If the car is level go to the TOP FLOOR procedure.
5. If the car is not level, navigate to the MAIN MENU | SETUP | FLOOR LEVELS
| TOO HIGH/TOO LOW screen.
6. Use the up and down arrow keys to specify how high or low the car is relative
to the landing. Save the value. Be sure the car does not leave the target floor
until the value has finished saving or that value may get applied to the next
floor the car stops at.
7. Send the car down to a lower floor then back up to the target floor. The car
should now stop level with the floor. If not, repeat steps 5-6.
