174
NORMAL LIMIT TESTING SETUP
Special Note:
When testing the limits at the top landings the car should be empty to
provide the proper speeds.
When testing the limits at the bottom landings the car should be fully
loaded to overcome the counterweight and provide the proper speeds.
SPEED PROFILES:
During the various testing procedures certain speeds of your car may
have to be adjusted. These speeds are located in profiles labeled S1, S2,
S3…S8 and are usually different for every job. These profiles are located
in MAIN MENU | SETUP | SPEEDS & SLOWDOWNS.
Use the following chart to record your car speeds.
MAIN MENU|SETUP|SPEEDS & SLOWDOWNS|S1..S8
S1 Speed: _____ FPM
MAIN MENU|SETUP|SPEEDS & SLOWDOWNS
Contract Speed: _______FPM
Inspection Speed: _____ FPM
Leveling Speed: _______FPM
TOP SPEED PROFILE:
Hydro controllers only have one speed profile as there is only high and
leveling. The S1 profile will be the one that is adjusted for all high speed
testing.
