HOISTWAY SWITCH POSITIONING TABLE – NTS
Hoistway Switch Positioning Table
Contract
Speed
UT1 / DT1
[inches from
terminal DZ]
UT2 / DT2
[inches from
terminal DZ]
UT3 / DT3
[inches from
terminal DZ]
10 - 50
5”
51 - 75
7”
76 - 100
9”
100 - 125
11”
126 - 150
13”
151 - 175
15”
176 - 200
17”
201 - 250
21”
251 - 300
27”
301 - 350
33”
351 - 400
39”
401 - 450
45”
451 - 500
51”
