CAR SPEED PROFILES OVERVIEW
Tractions - The Smartrise Controller has individual “Speed Profiles” programmed
to operate the car at different speeds based on demand.
Each Speed Profile has the following:
Speed
The speed the car is expected to achieve (and sustain for 1 second or
more) when that profile is selected for a run.
Slowdown Distance
The distance from the target floor that the controller will command a
speed reduction to leveling speed.
S# All – Changes all settings to same value
S# Up Normal – Changes the slowdown going UP into a floor for ALL
floors (including terminal landings)
S# Down Normal – Changes the slowdown going DOWN into a floor
for ALL floors (including terminal landings)
S# Up NTS – Changes the slowdown going UP into the TOP terminal
landing ONLY
S# Down NTS – Changes the slowdown going DOWN into the Bottom
terminal landing ONLY
Minimum Run Distance
The minimum distance a call must have in order for this speed profile to
be selected for a run.
This setting is the one that determines which speed profile is used
based on the distance the car is traveling (one floor, two floors, etc.).
Hydros only have one Fast and Slow speed so the controller only uses
one Speed Profile (S1) which is equal to the Contract Speed. The slow
speed is normally equal to the leveling speed.
