ETS SLOWDOWN TEST
1. This procedure will test the UET (up) and DET (down) stopping devices. The
procedure will demonstrate that the car will emergency stop (e-stop) as it
passes the ETS locations at contract speed. To demonstrate the operation of
the ETS, both the software normal stopping means and the normal terminal
stopping device (NTS) will need to be bypassed.
2. On MR controller turn on Dip switch #3 to disable door operation during
testing.
3. Prior to starting this procedure take a moment and write down the
parameters for S# Slowdowns. This is found by going to the MAIN MENU |
SETUP | SPEEDS & SLOWDOWNS | S1 | S1 SLOWDOWNS.
4. Write down the following 5-digit number for the parameters below:
a. S1 UP Normal – Value:__________
b. S1 UP NTS – Value: __________
c. S1 Down Normal – Value:__________
d. S1 Down NTS – Value: __________
5. These values will need to be manually restored after the ETS testing is
completed.
6. Command the Car to several floors away from a top terminal and disable the
normal stopping means by:
7. Go to MAIN MENU | SETUP | SPEEDS & SLOWDOWNS | S1 | S1
SLOWDOWNS | UP __.
a. S1 UP Normal – set to 00001. Save this parameter.
b. S1 UP NTS – set to 00001. Save this parameter.
8. Initiate a car call from MAIN MENU | DEBUG | ENTER CAR CALLS to send the
car to the top terminal landing. Manual car calls will only work from the MR
or CT SRU boards.
9. Run the car at contract speed to the top terminal landing and verify that the
car e-stops (faults). The fault should be “F81:UETS Overspeed”.
10. When testing is complete for the top landing restore the previous recorded
S1 UP Normal & S1 UP NTS parameter from (Step 4a-b).
11. Go to MAIN MENU | SETUP | SPEEDS & SLOWDOWNS | S1 | S1
SLOWDOWNS | S1 DOWN __.
a. S1 DOWN Normal – set to 00001. Save this parameter.
b. S1 DOWN NTS – set to 00001. Save this parameter.
12. Run the car at contract speed from several floors above the bottom terminal
