STOP RING TEST – LOW SPEED
1. Make sure the hoistway and car-top are clear of any personnel and then
move the car to the top landing of the hoistway.
2. Go to MAIN MENU | SETUP | MISC | BYPASS TERM LIMITS and set to “Yes”.
3. Verify that only the UPL valve goes on when moving in Inspection Speed. If
not, go to MAIN MENU | SETUP | SPEEDS & SLOWDOWNS | INSPECTION
SPEED and lower it enough that only the UPL valve actuates when moving in
Inspection Mode.
4. Bypass upper final limit switch (if installed).
5. Install a jumper from UT1 (or UET Switch) on the din rail to M24.
6. Run car slowly up onto stop ring using Machine Room Inspection mode.
7. When test is complete, lower car back down to the top landing door zone.
8. Set Bypass Term Limits back to “No”.
9. Set the Inspection Speed back to original value (if changed).
