Smartrise F220

131
FINAL SWITCH PLACEMENT - TAPE
Top Final Limit Switch (TFL) - Min 3” travel from Normal Limit
Top Normal Limit - [Activated at DZ magnets edge]
Door Zone Magnet (DZ)
Top
Terminal
Landing
Door Zone Magnet (DZ)
Bottom Final Limit Switch (BFL) - Min 3” travel from Normal Limit
Bottom Normal Limit (NL) - [Activated at DZ magnets edge]
Bottom
Terminal
Landing
