136
Smoke 4 – Smoke 4 should be programmed to flash the in-car fire lamp.
This input should connect to any machine room or hoistway smoke sensor whose
activation sends the car to the Alternate Level.
If the machine room is located at the Main Level, its smoke sensor should be
connected to this input to send the elevator to the Alternate Level.
Consult your local code to determine which hoistway smoke sensors should send
the elevator to the Alternate Level and connect them to this input.
Programming Smoke Sensor Floor Recalls
Go to MAIN MENU | SETUP | FIRE/EARTHQUAKE. For each smoke sensor (1-4) -
Enter the floor location the car is to be recalled to once that sensor is activated.
Note: The Fire Key is the same as Smoke 1.
Programming Smoke Fire Hat Flashing
If the code requires a specific smoke to flash the fire hat in the Car Station and
Hoistway, go to MAIN MENU | SETUP | FIRE/EARTHQUAKE | FLASH ON SMOKE
2~4, set the smoke sensor option to “YES” and then save it.
