Smartrise F220

237
F127
Term Limits
The “Bypass Terminal Limits” parameter was left on
Causes
The controller will not allow the car to run on automatic operation if the Bypass Terminal
Limits parameter is turned on.
Remedies
Turn the parameter off by setting MAIN MENU | SETUP | MISC | BYPASS TERM LIMITS = ”NO”
Check status of the following jumper located on SRU board and set per job specific provided
drawings:
Rev 5-7 SRU – Jumper J19
Rev 8 SRU – Jumper J24
F128
Overloaded
Car overload input is active
Causes
The car is on automatic operation and the overload input is indicating that too much weight is
in the car.
Remedies
Remove weight from the car until below rated capacity.
Verify that load weighing device is wired and configured correctly.
F129
RST #2 UN
Causes
Reset faults other than F130 and F131 may indicate a defective SRU board or mis-programmed
software.
Remedies
For F129, or F132 – F136, contact Smartrise as this may indicate a bad board or software.
F130
Power-on
Reset or Power-on of one of the computer processors
Causes
Loss of power to an SRU board will generate an F130 on the J21 and J22 processors.
A short circuit on the M24 or C24 bus will cause the power supply to shut off while the short is
present. This will result in an F130 fault when the short is corrected.
AC power present on the M24 or C24 DC power busses may cause and F130 or F131 fault.
Reset faults other than F130 and F131 may indicate a defective SRU board or mis-programmed
software.
Remedies
For F130 faults, check power to SRU boards. Verify M24 and C24 busses read 24vdc and that
the wires are not loose.
For F130 faults reported by CPU A or B, check for a short on the M24 bus. This includes power
to the hoistway and hall call stations.
For F130 faults reported by CPU C or D, check for a short on the C24 bus. This includes wiring
on the cartop and COP stations.
