58 Service Manual
5 Pin Descriptions
Refer to the following table and sections
Table 5-1 Codes and Names of Connection Cables
No. P/N Description Figure
1 2275.00468 S30 Display Power Cable See Figure 5-2
2 2275.00469 S30 Display DVI Signal Cable See Figure 5-3
3 2275.00060 S40 Trackball Signal Cable See Figure 5-4
4 2275.00482 S30 PS2 Conversion Cable See Figure 5-5
5 2275.00472 S30 Keyboard Signal Cable See Figure 5-6
6 2275.00473 S30 Keyboard Power Cable See Figure 5-7
7 2275.00474 S30 Keyboard and Mouse Control Cable See Figure 5-8
8 2275.00242 S40 9.7āā Signal Cable See Figure 5-9
9 2275.00057 S40 ARM Board USB Signal Cable See Figure 5-10
10 2275.00476 S30 Touch-Screen Signal Cable See Figure 5-11
11 2275.00491 S30 LED Indicator Control Signal Cable See Figure 5-12
12 2275.00483 S30 LED Indicator Board Cable See Figure 5-13
13 2275.00517 SSI-8000 Back Panel Power Connection Cable See Figure 5-14
14 2275.00471 S30 Power Switch Cable See Figure 5-15
15 2275.027903 SSI-8000 Power Input Cable See Figure 5-16
16 2275.00540 S30 DBF USB Transmission Cable See Figure 5-17
17 2275.00438 SSI-8000 VGA Signal Cable See Figure 5-18
18 2275.00014 SSI-8000 S Terminal Signal Cable See Figure 5-19
19 2275.00470 S30 HDMI Signal Cable See Figure 5-20
20 2275.00467 S30 PS-ON Signal Cable See Figure 5-21
21 2275.00462 S30 Drive Signal Cable (with rings at two ends) See Figure 5-22
