4-73
DCR-PC6E/PC9/PC9E
4-3. WAVEFORMS
CF-085 BOARD
CAMERA REC
2 IC3201 2
3 IC3201 3
1 IC3201 1
6.5Vp-p
H
18.0Vp-p
6.5Vp-p
H
18.0Vp-p
V
H
4 IC3201 4
5 IC3201 qd
18.0Vp-p
H
6 IC3201 qs
3.6Vp-p
55.6 nsec
7 IC3201 0
2.7Vp-p
H
8 Q3201 E
V
0.9Vp-p
PD-148/148A BOARD
REC/PB
1 IC2101 rh
560mVp-p
H
8 IC2103 wh
2.1Vp-p
48 nsec
9 IC2103 rk
2.8Vp-p
V
2 IC2101 rj
480mVp-p
H
3 IC2101 rk
600mVp-p
H
4 IC2101 w;
8.0Vp-p
2H
5 IC2101 ws
8.0Vp-p
2H
6 IC2101 wf
8.0Vp-p
2H
7 IC2103 1
2.8Vp-p
H
WAVEFORMS
CF-085, PD-148/148A
Waveforms and parts location of the
VC-265/265A board are not shown.
Pages from 4-74 to 4-77 are not
shown.
