Sony DCR-PC6E - Electrical Parts List

6-9
6-2. ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
CND: Canadian model
KR: Korea model
AUS: Australian model
CN: Chinese model
HK: Hong Kong model
JE: Tourist model
A-7074-874-A BJ-002 BOARD, COMPLETE (PC9/PC9E)
********************************
A-7074-903-A BJ-002A BOARD, COMPLETE (PC6E)
*****************************
(Ref.No.;30000 Series)
< CAPACITOR >
C3100 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C3101 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
(PC9/PC9E)
< CONNECTOR >
CN3100 1-691-550-11 PIN, CONNECTOR (1.5MM)(SMD) 3P (DC IN)
CN3102 1-794-276-11 CONNECTOR, SQUARE TYPE 4P (DV IN/OUT)
CN3103 1-794-962-11 CONNECTOR, SQUARE TYPE (USB 5P) (USB)
(PC9/PC9E)
CN3105 1-691-550-61 PIN, CONNECTOR (1.5MM)(SMD) 3P
CN3106 1-794-996-21 PIN, CONNECTOR 16P
CN3107 1-794-377-21 PIN, CONNECTOR 8P
CN3108 1-794-403-21 CONNECTOR, BOARD TO BOARD 60P
< DIODE >
D3100 8-719-077-57 DIODE DF3A8.2C(TPL3)
D3101 8-719-056-48 DIODE 1SS388(TPL3)
D3102 8-719-056-23 DIODE 1SS387-TPL3 (PC9/PC9E)
D3103 8-719-062-16 DIODE 01ZA8.2(TPL3) (PC9/PC9E)
D3104 8-719-070-93 DIODE TLAU1008(T05,SOY)
D3105 8-719-027-76 DIODE 1SS357-TPH3
D3106 8-719-062-16 DIODE 01ZA8.2(TPL3)
< FUSE >
0 F3100 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0 F3101 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0 F3102 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0 F3103 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0 F3104 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
0 F3105 1-576-406-21 FUSE, MICRO 1.4A 32V (1608)
< LINE FILTER >
LF3101 1-419-100-21 INDUCTOR 0uH (PC9/PC9E)
LF3102 1-419-100-21 INDUCTOR 0uH (PC9/PC9E)
< TRANSISTOR >
Q3100 8-729-047-68 TRANSISTOR SSM3K03FE(TPL3)
0 Q3101 8-729-051-49 TRANSISTOR TPC8305(TE12L)
Q3102 8-729-043-60 TRANSISTOR CPH6102-TL
Q3103 8-729-050-91 TRANSISTOR UNRL21300AS0
Q3104 8-729-050-91 TRANSISTOR UNRL21300AS0
< RESISTOR >
R3100 1-218-990-11 SHORT 0
R3101 1-218-953-11 RES-CHIP 1K 5% 1/16W
R3102 1-218-985-11 RES-CHIP 470K 5% 1/16W
R3103 1-218-989-11 RES-CHIP 1M 5% 1/16W
R3105 1-216-150-91 RES-CHIP 10 5% 1/8W
R3106 1-218-953-11 RES-CHIP 1K 5% 1/16W
R3107 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R3108 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R3111 1-218-990-11 SHORT 0
R3113 1-218-990-11 SHORT 0
************************************************************
A-7074-869-A CF-085 BOARD, COMPLETE
**********************
(Ref.No;20000 Series)
(IC3201 is not included in this complete board.)
< CAPACITOR >
C3201 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C3202 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C3203 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C3204 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C3454 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3455 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3456 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C3457 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C3458 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C3459 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C3460 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C3461 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C3462 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C3463 1-125-817-11 CERAMIC CHIP 10uF 10% 6.3V
C3464 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C3465 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C3466 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3467 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C3469 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C3702 1-107-820-11 CERAMIC CHIP 0.1uF 16V
BJ-002 CF-085
