5-44
4. AGC Center Level and APC & AEQ Adjustment
4-1. Preparations before adjustments
Mode Camera recording
Subject Arbitrary
Adjusting method:
Order Page
Address
Data Procedure
1 2 30 40 Set the data.
2 Record the camera signal for
three minutes.
3. Switching Position Adjustment (VC-265 board)
Mode VTR playback
Signal SW/OL reference tape (XH2-3)
Measurement Point Display data of page: 3, address: 03
Measuring Instrument Adjustment remote commander
Adjustment Page C
Adjustment Address 10, 11, 12, 13
Specified Value 00
Adjusting method:
Order Page
Address
Data Procedure
1 Insert the SW/OL reference tape
and enter the VTR STOP mode.
2 0 01 01 Set the data.
3 C 10 EE Set the data, and press PAUSE
button.
4 3 21 Check that the data is “02”.
(Note1)
5 3 01 0D Set the data, and press PAUSE
button.
6302
Check that the data changes to “00”.
7 3 03 Check that the data is “00”.
(Note2)
8 C 10 Check that the data is other than
“EE”. (Note3)
9 0 01 00 Set the data.
Note1: If the data of page: 3, address: 21 is “72”, the tape top being played.
After playing the tape for 1 to 2 seconds, stop it, perform step 4
and higher.
Note2: If bit 0 of the data is “1”, the EVEN channel is defective. If bit 1 is
“1”, the ODD channel is defective. Contents of the defect is written
into page: C, addresses: 10 and 12. See the following table. (For
the bit values, refer to “5-4. SERVICE MODE”, “4-3. 3. Bit value
discrimination”. ) If bit 3 of the data is “1”, the tape end being
played, so rewind the tape and perform the adjustment again.
Note3: If the data is “EE”, the adjustmnet is not done. So perform this
adjustment again.
When the EVEN channel is defective
Data of page: C, Contents of defect
address: 10
EE Writing into EEPROM (IC4701) is
defective
E8 Adjustment data is out of range
E7 No data is returned from IC5302
(CAIN)
When the ODD channel is defective
Data of page: C, Contents of defect
address: 12
EE Writing into EEPROM (IC4701) is
defective
E8 Adjustment data is out of range
E7 No data is returned from IC5302
(CAIN)
