Sony DCR-PC6E - Mounted Parts Location

4-78E
DCR-PC6E/PC9/PC9E
PARTS LOCATION
NS-013, CF-085, BJ-002/002A, PD-148/148A
BJ-002/002A BOARD
* C3100 A-6
* C3101 B-6
CN3100 C-6
CN3102 C-6
CN3103 C-6
CN3105 C-6
* CN3106 A-1
* CN3107 A-1
* CN3108 B-3
D3100 C-6
* D3101 A-6
* D3102 B-6
* D3103 A-6
* D3104 A-6
D3105 C-6
D3106 C-1
* F3100 B-3
* F3101 B-3
* F3102 B-3
* F3103 B-3
* F3104 B-3
* F3105 A-3
* LF3101 B-6
* LF3102 A-6
* Q3100 A-6
* Q3101 A-6
Q3102 C-6
Q3103 C-6
* Q3104 A-6
R3100 C-6
R3101 C-6
* R3102 A-6
* R3103 A-6
* R3105 A-6
R3106 C-6
R3107 C-6
* R3108 A-6
R3111 C-6
* R3113 A-3
* R3114 B-6
* R3115 A-6
* R3116 A-6
* R3117 A-6
NS-013 BOARD PD-148/148A BOARD
C2101 C-2
C2102 D-1
C2103 D-1
C2104 B-1
C2105 B-1
C2106 D-1
C2107 C-1
C2108 C-1
C2109 C-1
C2110 C-1
C2111 C-2
C2112 D-2
C2113 C-2
C2114 D-2
C2115 D-3
C2116 C-2
C2117 C-2
C2118 D-2
C2119 D-2
C2120 D-2
C2123 C-3
C2124 C-3
C2125 C-3
C2126 B-3
C2127 C-3
C2128 B-3
C2130 D-1
C2132 C-2
C2133 B-3
C2134 D-1
C2181 C-3
C2182 B-3
C2183 C-3
C2184 C-3
C2185 C-3
C2186 D-3
CN2100 C-1
CN2101 B-1
CN2103 B-3
CN2104 A-2
CN2105 D-3
D2101 C-1
D2102 C-2
D2104 B-3
D2106 B-3
D2181 A-3
IC2101 D-2
IC2103 B-2
L2101 C-1
L2102 C-1
L2103 D-3
L2104 C-2
L2181 C-3
L2182 C-3
Q2101 D-3
Q2102 C-3
Q2103 C-3
Q2104 C-3
Q2109 C-3
Q2111 C-1
Q2112 B-3
Q2181 C-3
Q2182 D-3
Q2183 B-3
R2109 D-1
R2110 D-1
R2111 D-1
R2112 C-1
R2114 D-2
R2115 C-2
R2116 C-2
R2117 C-2
R2118 C-2
R2119 C-2
R2122 C-2
R2124 C-2
R2134 C-3
R2136 C-2
R2137 C-2
R2138 C-3
R2143 D-3
R2144 C-3
R2147 C-3
R2148 C-3
R2157 B-3
R2158 C-3
R2159 B-3
R2160 B-3
R2166 B-3
R2168 D-1
R2169 D-1
R2170 C-1
R2177 B-3
R2178 C-3
R2179 C-2
R2180 C-2
R2181 D-3
R2182 D-3
R2183 A-4
R2202 B-2
R2203 B-2
R2204 B-2
R2205 B-2
R2206 B-3
R2207 D-3
CF-085 BOARD
C3201 B-3
C3202 A-3
C3203 A-3
* C3204 A-8
C3206 A-3
C3209 A-4
C3454 E-4
* C3455 D-6
C3456 E-4
C3457 D-5
C3458 E-4
C3459 D-5
* C3460 D-6
* C3461 D-6
* C3462 D-6
* C3463 D-6
C3464 D-5
C3465 C-5
C3466 D-4
C3467 D-5
C3468 C-4
C3469 D-4
C3470 E-4
C3701 C-2
C3702 C-2
CN3351 D-2
CN3353 D-1
* CN3354 B-9
CN3355 D-1
CN3701 G-5
* CN3702 G-6
D3351 D-1
D3352 D-1
IC3201 A-4
IC3451 D-4
IC3701 C-2
L3201 A-3
L3451 C-5
no mark: side A
* mark : side B
4-4. MOUNTED PARTS LOCATION
D6001 A-1
D6003 B-1
D6002 B-1
IC6001 A-1
Q3201 A-3
Q3701 D-2
Q3702 D-2
Q3703 D-3
R3201 A-3
R3351 D-1
R3352 D-1
R3451 E-4
* R3452 D-6
* R3453 D-6
R3454 E-4
R3455 D-4
R3456 D-5
R3457 D-4
R3458 D-5
R3459 D-5
R3460 D-5
R3461 C-4
R3462 D-4
R3463 E-4
R3701 D-2
R3702 D-3
* R3704 G-6
* R3705 G-6
R3706 D-2
* R3707 G-6
R3708 D-3
R3709 D-2
* R3710 G-6
* R3711 G-6
* R3712 G-6
R3713 D-3
* SE3450 D-7
* SE3451 D-7
TH3701 D-3
