6-10
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
PD-148
< CONNECTOR >
CN3351 1-691-362-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN3353 1-794-411-21 CONNECTOR, FFC/FPC (LIF) 8P
CN3354 1-794-404-21 CONNECTOR, BOARD TO BOARD 88P
CN3355 1-794-766-21 CONNECTOR, FFC/FPC (LIF) 6P
CN3701 1-691-370-11 CONNECTOR, FFC/FPC 6P
CN3702 1-691-354-21 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
D3351 8-719-056-61 DIODE 015AZ8.2-TPL3
< IC >
IC3201 A-7031-074-A CCD BLOCK ASSY (CCD IMAGER)(PC6E/PC9E)
IC3201 A-7031-075-A CCD BLOCK ASSY (CCD IMAGER)(PC9)
IC3451 8-759-489-19 IC uPC6756GR-8JG-E2
IC3701 8-759-581-11 IC NJM2125F(TE2)
< COIL >
L3201 1-414-757-11 INDUCTOR 100uH
L3451 1-414-771-91 INDUCTOR 10uH
< TRANSISTOR >
Q3201 8-729-117-73 TRANSISTOR 2SC4178-F13F14-T1
Q3701 8-729-420-20 TRANSISTOR XN4312-TW
Q3702 8-729-042-26 TRANSISTOR 2SB1462J-QR(K8).SO
Q3703 8-729-427-83 TRANSISTOR XP6501-(TX).SO
< RESISTOR >
R3201 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R3351 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R3451 1-218-969-11 RES-CHIP 22K 5% 1/16W
R3452 1-218-969-11 RES-CHIP 22K 5% 1/16W
R3453 1-218-969-11 RES-CHIP 22K 5% 1/16W
R3454 1-218-969-11 RES-CHIP 22K 5% 1/16W
R3455 1-218-965-11 RES-CHIP 10K 5% 1/16W
R3456 1-218-965-11 RES-CHIP 10K 5% 1/16W
R3457 1-218-989-11 RES-CHIP 1M 5% 1/16W
R3458 1-218-967-11 RES-CHIP 15K 5% 1/16W
R3459 1-218-989-11 RES-CHIP 1M 5% 1/16W
R3460 1-216-864-11 METAL CHIP 0 5% 1/16W
R3461 1-216-864-11 METAL CHIP 0 5% 1/16W
R3462 1-216-864-11 METAL CHIP 0 5% 1/16W
R3463 1-216-864-11 METAL CHIP 0 5% 1/16W
R3701 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R3702 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R3706 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R3708 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3709 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3711 1-218-990-11 SHORT 0
R3712 1-218-990-11 SHORT 0
< SENSOR >
SE3450 1-803-042-41 SENSOR, ANGULAR VELOCITY
(PITCH SENSOR)
SE3451 1-803-042-31 SENSOR, ANGULAR VELOCITY (YAW SENSOR)
< THERMISTOR >
TH3701 1-810-811-11 THERMISTOR, NTC (1608)
************************************************************
FP-102 FLEXIBLE BOARD (Not supplied)
********************************
< DIODE >
D901 8-719-078-71 DIODE LN57A,SO (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 HOLE ELEMENT HW-105A-CDE-T (S REEL)
H902 8-719-067-74 HOLE ELEMENT HW-105A-CDE-T (T REEL)
< TRANSISTOR >
Q901 8-729-028-71 TRANSISTOR PN-166,SO (TAPE END)
Q902 8-729-028-71 TRANSISTOR PN-166,SO (TAPE TOP)
< SWITCH >
S901 1-572-288-11 SWITCH, PUSH (C.C. DOWN)
************************************************************
A-7074-870-A MF-325 BOARD, COMPLETE
**********************
(Ref.No;20000 Series)
< RESISTOR >
R6201 1-218-945-11 RES-CHIP 220 5% 1/16W
************************************************************
A-7074-867-A NS-013 BOARD, COMPLETE
**********************
(Ref.No;20000 Series)
< DIODE >
D6001 8-719-061-82 DIODE TLSU1002 (TPX1,SONY)
D6002 8-719-078-78 DIODE DCZ2805
D6003 8-719-078-78 DIODE DCZ2805
< IC >
IC6001 8-749-013-13 IC RS-70-TU
************************************************************
A-7074-871-A PD-148 BOARD, COMPLETE (PC9/PC9E)
********************************
A-7074-902-A PD-148A BOARD, COMPLETE (PC6E)
******************************
(Ref.No;20000 Series)
< CAPACITOR >
C2101 1-113-988-11 TANTAL. CHIP 68uF 20% 4V
C2102 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2104 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C2105 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2108 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2109 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2110 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2111 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C2112 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
FP-102 NS-013MF-325
Be sure to read “Precautions upon replacing CCD imager”
on page 4-12 when changing the CCD imager.
CF-085
