397Color Corrector Functions
Chapter 19 Color Corrector
RGB Clip Operations
Making RGB clip adjustments
Use the following procedure.
1
In the CCR menu, press VF1 ‘CCR1’ and HF4 ‘RGB Clip.’
The RGB Clip menu appears.
2
In the <RGB Clip> group, press [RGB Clip], turning it on.
3
In the <RGB Clip Adjust> group, select the item you want to adjust.
Dark: dark clip adjustment
White: white clip adjustment
4
Adjust the following parameters.
To return the parameters to their default settings
In the <RGB Clip> group, press [Unity].
Luminance Processing Operations
Applying luminance processing
Use the following procedure.
1
In the CCR menu, press VF1 ‘CCR1’ and HF5 ‘Luminance Process.’
The Luminance Process menu appears.
2
In the <Luminance Process> group, press [Luminance Process], turning it
on.
3
In the <Mode> group, specify the adjustment mode.
Knob Parameter Adjustment Setting values
1 Red Red signal adjustment –50.00 to +150.00
2 Green Green signal adjustment –50.00 to +150.00
3 Blue Blue signal adjustment –50.00 to +150.00
4 All Simultaneous RGB adjustment Red value is shown
