outputs « < » ; inputs NO « > » inputs NC « > / »
PE1-M
AR1-M
< FM
(not used)
< GND
ground
< FD
(not used)
< GND
ground
< AF
(not used)
> STH
Oil heat switch
< DFT
Out of service
> MR
Emergency operation switch
PE2-M
MC2-M
> / FCF1
(not used)
> TH
Machinery heat switch
> / FCO1
(not used)
< GND
ground
> CHC1
(not used)
< masse
screening
> / CPC1
(not used)
MC1-M
> FAC 1
(not used)
> 1
(not used)
< GO
GONG
< 2
(not used)
> SU
Overload
< 5
(not used)
> / NSC
No full stop
< 8
(not used)
PE3-M
CN2-M RS485
> MI
Inspection up
< 1
Data – (A)
> INS
Inspection switch
< 2
Data + (B)
> DI
Inspection down
< 3
GND
> CCC
(not used)
< 4
GND
PE4-M
CN1-M RS485
> DTC
(not used)
< 1
Data – (A)
> C
(not used)
< 2
Data + (B)
> B
(not used)
< 3
GND
> A
(not used)
< 4
GND
PE5-M
CN5-M
>C1 à C8
Car and floor buttons
< 1
24 V
PE6-M
< 2
ground
< V24
24 V DC
< 3
24 V
< V12
12 V DC
< 4
ground
< V9
9 V DC
< 5
CANH
< GND
ground
< 6
CANL
TR1-M
CN6-M
< GND
ground
< 1
24 V
> /RB
(not used)
< 2
GND
> /RH
(not used)
< 3
24 V commanded
> /CPO
Fire man key
< 4
ground
TR2-M
< 5
CANH
> P1 à P8
Car and floor buttons
< 6
CANL
TR3-M
CN7-M et CN8-M
< GND
ground
< 1
24 V
< AF
Landing display
< 2
GND
< V9
(not used)
< 3
24 V
< V12
12 V DC
< 4
ground
< PN
ground
< 5
(not used)
< V24
24 V DC
< 6
(not used)
< FM
Up arrow
< 7
CANH
< FD
Up arrow
< 8
CANL
