USER MANUAL « ASP 116 EVOLUTION »
BOARDS
Sprinte SAS, All rights reserved, including translation rights
80
LED
STATUS
INFORMATION
V24C
ON
24V commanded
VCC
ON
216SP board powered
DFT
ON
Indicates that the device is not working the LED flashes if boot is faulty
CABINE
MACHINE
MULTIPLEX
FCF1
ON
(not used)
FCO1
ON
(not used)
CHC1
ON
(not used)
CPC1
ON
(not used)
FAC1
ON
(not used)
SU
ON
110% of maximum authorised car load reached.
NSC
ON
80% of maximum authorised car load reached.
INS
ON
(not used)
CCC
ON
(not used)
DTC
BLINK
(not used)
C
OFF
(not used)
B
OFF
(not used)
A
OFF
(not used)
C1 à C8
ON
Sending taken into account.
RB
ON
(not used)
RH
ON
(not used)
CPO
ON
Fireman’s key activated.
P1 à P8
ON
Call taken into account.
STH
ON
(not used)
MR
ON
Control panel in emergency mode
OUV1
ON
Door 1 opening command activated.
FER1
ON
Door 1 closing command activated.
