USER MANUAL « ASP 116 EVOLUTION »
BOARDS
Sprinte SAS, All rights reserved, including translation rights
87
CB1 - BAB 1A
CB2 - decelerators
<V24C
24 V controlled
<GND
ground
<GND
ground
>RH
Top decelerator
>C1 to C8
Car button 1 to 8
<GND
ground
<FM
Up arrow
>RB
Bottom decelerator
<FD
Down arrow
<GND
ground
>BPALAR
Alarm button
<PE
Equipotential protection
>ECL
Emergency lighting
CB3 - Reader
>FAC1
Accelerated closing service 1
<V12
12 V
>OAC1
Accelerated opening service 1
>D
Reader fault
>HP1C
Car loud speaker
<GND
ground
<AF
Display
>A
Reader input A
<GND
ground
<GND
masse
<PE
Equipotential protection
>B
Reader input B
CB4 – load weighing gauge
<GND
ground
<V24C
24 V controlled
>C
Reader input C
<V24C
24 V controlled
>Y11
ILS1 input for levelling
<GND
ground
>Y12
ILS1 input for levelling
<GND
ground
>Y21
ILS2 input for levelling
>CAP1
Input gauge 1
>Y22
ILS2 input for levelling
>CAP2
Input gauge 2
CB5 – inspection
<V24C
24 V controlled
<V24C
24 V controlled
<V24C
24 V controlled
<GND
ground
<GND
ground
>BFER1
Closing button service 1
<GND
ground
>BOUV1
Opening button service 1
>CAP3
Input gauge 3
>INS
Inspection button
>CAP4
Input gauge 4
>LUG
Shaft light button
>MI
Inspection up
>DI
Inspection down
>BTELI
Telephone button
>BTELI
Telephone button
