USER MANUAL « ASP 116 EVOLUTION »
BOARDS
Sprinte SAS, All rights reserved, including translation rights
89
CB11 – CANBUS / RS485 expansion
CB13 – CANBUS output
<V24
24 V
<V24C
24 V controlled
<GND
ground
<GND
ground
(reserved)
<GND
ground
(reserved)
>BLI
Shielding
<SCD_SUIV
Next control
<CAN1_H
CANBUS 1 HIGH
>BLI
Shielding
<CAN1_L
CANBUS 1 LOW
<RS485_H
Output RS485
<RS485_L
Output RS485
<CAN0_H
CANBUS 0 HIGH
<CAN0_L
CANBUS 0 LOW
CB14 – Power supplies
<V24
24 V
<GND
ground
<V24
24 V
<GND
Earth
<V12
12 V
<GND
ground
LED
INFORMATION
CHC1
Shock Input
CPC1
Cell output
DIS
Discriminator output
INS
Inspection input
ISHC
IDHCS_AV
RH
Top decelerator
RB
Bottom decelerator
A
Reader A input
B
Reader B input
C
Reader C input
ETAT
CANBUS status
V12
12 V present
V24
24 V present
V24C
24 V controlled present
