165
APPENDIX
A
Connector Pinouts
This appendix gives you reference information about the system’s rear panel ports
and pin assignments. Topics covered in this appendix include:
■ “Reference for the Serial Port A and B Connectors” on page 166
■ “Reference for the USB Connectors” on page 167
■ “Reference for the Twisted-Pair Ethernet Connector” on page 168
■ “Reference for the System Controller Ethernet Connector” on page 169
■ “Reference for the System Controller Serial Connector” on page 170
