172 Sun Fire V890 Server Owner’s Guide • September 2004
Reference for Physical Specifications
The dimensions and weight of the system are as follows.
Reference for Electrical Specifications
The following table provides the electrical specifications for the system.
Measurement U.S. Metric Comments
Height (with casters) 28.1 in 71.4 cm
Width 18.9 in 48.0 cm
Depth 32.9 in 83.6 cm
Weight:
Minimum
Maximum
194.0 lb
288.0 lb
88.0 kg
130.6 kg
Actual weight depends on the
installed options
Power Cord 8.2 ft 2.5 m
Parameter Value
Input
Nominal Frequencies 50 Hz or 60 Hz nominal
Nominal Voltage Range Autoranging 200 to 240 VAC
Maximum Current AC RMS 8 A @ 200 VAC (each power cord for two
power supplies per system)
AC Operating Range 180 to 264 Vrms, 47 - 63Hz
Output
+3.3 VDC 3 to 72 A
+5 VDC 3 to 56 A
+12 VDC 1 to 35 A
+48 VDC 0 to 50 A
Maximum DC Power Output 2509 Watts
Maximum System AC Power Consumption 3200 Watts
Maximum System Heat Dissipation 10,912 BTU/hr
Volt-Ampere Rating 2078 VA with 1629 Watt load (PF=0.98)
