Suzuki DF15 - Recoil Starter Removal and Disassembly

5-2 RECOIL STARTER
REMOVAL
1. Loosen the lock nuts 1 and remove NSI cable 2 from
cable bracket (stator base) 3.
2. Remove the NSI cable from clutch notch lever 4.
3. Remove the four (4) bolts securing recoil starter.
4. Remove the recoil starter assembly.
Bolt
