10-12 DF9.9/15 “K6” (’06) MODEL
SHIFT CAM SPRING PIN, SHIFT CAM AND SHIFT ROD
The diameter of shift cam spring pin has been changed from 2.15 mm to 2.65 mm.
The thickness of shift cam spring pin has been changed, 0.4 to 0.5.
In accordance with this change, the pin hole diameter of shift cam and shift rod has been changed.
2.0 mm 2.5 mm
Shift rod
Shift cam
Spring pin
2.15 mm 2.65 mm
2.0 mm 2.5 mm
2.3 mm 2.6 mm
Thickness
0.4 mm 0.5 mm
