8-8 LOWER UNIT
INSPECTION
NOTE:
Thoroughly wash all metal components with cleaning solvent
and dry with compressed air.

PROPELLER
• Inspect the propeller for bent, chipped or broken blades.
Replace or repair if necessary.
• Inspect the propeller bushing splines for wear or other dam-
age. Replace if necessary.
• Inspect the propeller bushing for deterioration or slipping.
Replace if necessary.
GEARCASE
• Inspect the gearcase for cracks or other damage.
Replace if necessary.
• Inspect the pinion bearing for pitting, rough or other damage.
Replace if necessary.
NOTE:
If removal and replacement are required, see the “PINION
BEARING” section on page 8-6.
GEARS
• Inspect the forward gear, reverse gear and pinion gear teeth
and engaging dogs for excessive wear or other damage.
Replace if necessary.
• Inspect the thrust bearing and forward gear bearing for pitting,
rough or other damage. Replace if necessary.
Wear the safety glasses when using compressed air.
