2 DF9.9T/TH/DF15 (Serial No. 110001 and later)
GENERAL INFORMATION
*SPECIFICATIONS (DF9.9T/TH)
*: These specifications are subject to change without notice.
DIMENSIONS & WEIGHT
PERFORMANCE
POWER HEAD
Item Unit
Data
DF9.9T
DF9.9TH
PRE-FIX 00993F
Overall length
(front to back)
mm (in) 668 (26.3)
Overall width
(side to side)
mm (in) 323 (12.7)
Overall height L mm (in) 1 220 (48.0)
X mm (in) 1 347 (53.0)
Weight
L
kg
(lbs)
53.5 (117.9) 54.5 (120.2)
X
kg
(lbs)
55.0 (121.3) 56.0 (123.5)
Transom height L mm (in. type) 545 (20)
X mm (in. type) 672 (25)
Maximum output kW (PS) 7.3 (9.9)
Recommended operating
range
r/min 4 900 – 5 500
Idle speed r/min 900 ± 50
In-gear idle speed r/min Approx. 820 – 920
Engine type 4-stroke SOHC
Number of cylinders 2
Bore mm (in) 58.0 (2.28)
Stroke mm (in) 57.0 (2.24)
Total displacement cm
3
(cu. in) 302 (18.4)
Compression ratio :1 9.0
Spark plug NGK CPR6EA-9
Ignition system SUZUKI PEI (Digital CDI)
Fuel supply system Carburetor (Number of carb.: 1)
Exhaust system Through prop exhaust
Cooling system Water cooled
Lubrication system Wet sump by trochoid pump
Starting system Electric
Choke system (Enrichener system) Automatic Manual
Throttle control Remote control Twist grip
