Suzuki DF15 - Df9.9 E;Df15 E

WIRE/HOSE ROUTING 9-3
DF9.9E/DF15E
RECTIFIER & REGULATOR
B
M
B
CAUTION LAMP
(OIL PRESSURE)
CDI UNIT
BATTERY 12V 35AH
MAGNETO
STARTER MOTOR
FUSE 20A
Bl/R
W/R
B
Br
Bl/R
W/R
B
Br
STARTER MOTOR RELAY
BATTERY CHARGE COIL
R
R
B
B
P
B
P
R R
Br
Y/G
B
B
Br
Y/G
B
G
R/B
Y/B
B/R
Br
Bl
P
Bl/R
Y/B
R
Y
R
W W
Bl
Y
R
B
B
B
B
Y/G
W
B
R
OIL PRESSURE SWITCH 15 kPa (0.15 kgf/cm
2
) or less
ON
START SWITCH PUSH START
NEUTRAL SWITCH N ON F.R OFF
O
O
O
IGNITION COIL
SPARK PLUG
PULSER COIL
CONDENSER CHARGE COIL
WIRE COLOR B ......... Black Bl ........ Blue Br ........ Brown G ......... Green O ......... Orange
P ......... Pink R ......... Red W ........ White Y ......... Yellow B/R ..... Black with Red tracer
BI/R ....... Blue with Red tracer R/B ........ Red with Black tracer W/R ....... White with Red tracer Y/B ........ Yellow with Black tracer Y/G ........ Yellow with Green tracer
EMERGENCY STOP & ENGINE STOP SWITCH
Emergency stop switch: Lock plate IN RUN Lock plate OUT STOP Engine stop switch: Button pushed STOP
