Suzuki DF15 - Tiller Handle; Removal

7-4 MID UNIT
TILLER HANDLE
REMOVAL
1. Remove the STBD side cover.
2. Loosen lock nuts 1.
3. Remove the throttle rod 2 from throttle lever 3.
4. Remove the bolt 4, throttle lever 3 and throttle drum 5.
5. Remove the throttle cables 6 from throttle drum.
6. Disconnect emergency stop switch lead wire.
Disconnect starter switch lead wire.
7. Remove screw 7 and cable clamp 8
.
