LOWER UNIT 8-3
7. Remove the four bolts, then remove the water pump case B
and impeller C.
8. Remove the impeller key D and dowel pins E.
9. Remove the under panel F, under panel gasket, water inlet
housing G, gasket H, exhaust seal rubber I and exhaust
seal core J.
10. Remove the two bolts securing the propeller shaft bearing
housing K to the gearcase.
To prevent injury from propeller blades, wear gloves
and place a block of wood between the anti-cavitation
plate and the propeller blade tips to lock the propeller
in place.
