LOWER UNIT 8-5
2. Remove the spring 8 from clutch dog shifter.
3. Use special tool to push the dog pin 9 out of clutch dog
shifter.
09922-89810: Shift pin remover
4. Remove the clutch dog shifter 0 and spring A.
Disassembly of shift rod components
1. Push the pin 1 out and remove the clutch cam 2.
2. Remove the pin 3, washer 4, O-ring 5, O-ring 6, shift rod
guide 7 and boot 8.
