9-12 WIRE/HOSE ROUTING
Clamp
Clamp
Fuel hose/protector
Clutch notch lever
Fuel pump
• Route the fuel hose under
the clutch lever shaft.
• Do not route the fuel hose
under the clutch notch lever.
When installing fuel filter, ensure
that arrow mark points toward
the fuel pump side.
Fuel filter
