DF9.9/15 “K7” (’07) MODEL 11-15
Water pump case sleeve installation
1. Apply SUZUKI BOND “1207B” onto the outer-surface of water pump case sleeve.
2. Install the water pump sleeve into the water pump case by confirming the projection on the sleeve
should meet with the groove on the pump case.
99000-31140: SUZUKI BOND “1207B”
Water pump case
Water pump case sleeve
Projection
Groove
