Suzuki DF15 - Page 298

4 DF9.9T/TH/DF15 (Serial No. 110001 and later)
*SPECIFICATIONS (DF15)
*: These specifications are subject to change without notice.
DIMENSIONS & WEIGHT
PERFORMANCE
POWERHEAD
Item Unit
Data
DF15 DF15E DF15R
PRE-FIX 01503F
Overall length (front to back) mm (in) 668 (26.3)
Overall width (side to side) mm (in) 323 (12.7)
Overall height S mm (in) 1095 (43.1)
L mm (in) 1220 (48.0)
Weight S kg (lbs) 44 (97.0) 47.5 (104.7) 46.5 (102.5)
L kg (lbs) 45 (99.2) 48.5 (106.9) 47.5 (104.7)
Transom height
[Trim position: 3]
S
mm
(inch type)
422 (15)
L
mm
(inch type)
549 (20)
Maximum output kW (PS) 11.0 (15)
Recommended operating range r/min 5400 – 6000
Idle speed r/min 900 ± 50 (in-gear: approx. 870)
Engine type 4-stroke SOHC
Number of cylinders 2
Bore mm (in) 58.0 (2.28)
Stroke mm (in) 57.0 (2.24)
Total displacement cm
3
(cu in) 302 (18.4)
Compression ratio :1 9.0
Spark plug NGK CPR6EA-9
Ignition system SUZUKI PEI (Digital CDI)
Fuel supply system Carburetor (Number of carb. : 1)
Exhaust system Through prop exhaust
Cooling system Water cooled
Lubrication system Wet sump by trochoid pump
Starting system Manual Electric
Choke system (Enrichener system) Manual Automatic
Throttle control Twist grip Remote control
