3-40 IGNITION AND ELECTRICAL
NO-LOAD PERFORMANCE TEST
1. Connect battery and ammeter to starter motor as shown.
2. Check that starter rotates smoothly and steadily with pinion
moving out. Check that ammeter indicates specified current.
No load current: Within 90 A at 11 V
Before performing following test, secure the starter
motor to the test bench.
