8. V-BELT DRIVING SYSTEM
8-12
Measure each clutch weight thickness. Replace
it if exceeds service limit.
Service limit: 3.0 mm
Apply grease onto setting pins.
Install the spring into groove with pliers.
Install new clutch weight onto setting pin and then
push to the specified location.
Apply with grease onto setting pins.
Caution
Grease or lubricant will damage the clutch weight
and affect the block’s connection capacity.
