18. ELECTRICAL SYSTEM
18-15
Replacing Bulb of Taillight and Rear
Winker Light
Remove 2 screws.
Remove the taillight cover.
Replace with new taillight bulb.
(12V 5W/21W)
Remove 2 screws.
Remove the rear winker light cover.
Pull out the rear winker bulb.
Replace the rear winker bulb with new one.
(12V 10W)
Caution
Never touch the bulb with finger, which will
create a heat point and reduce the lifetime of
the bulb.
Clean any grease left on the bulb with alcohol.
To this chapter contents
2 screws
2 screws
Taillight bulb
