18. ELECTRICAL SYSTEM
18-1
Mechanism Diagram ·····························18-1
Maintenance Data··································18-2
Technical Specification ························18-2
Trouble Diagnosis·································18-3
Battery····················································18-4
Charging System···································18-5
Ignition System ·····································18-8
Starting System ······································18-10
Meters ······················································18-12
Light / Bulb··············································18-13
Switch / Horn···········································18-16
Cooling Fan Thermo Switch ··················18-19
Thermo Unit·············································18-20
Water Temperature Indicator Lamp ······ 18-20
Mechanism Diagram
Starter relay
Winker relay
Spark plug
AC. Generator
Fuse box
Battery
Ignition coil
Main switch
Full Transistor
Ignition Unit
Regulator rectifier
Shift gear
control unit
Horn
Start & light &
winker & horn &
brake switch
Headlight relay
Home page
Contents
Thermo unit
Hazard
control unit
18
Rear brake switch
Front brake switch
DC. Power outlet
Shaft gear control unit
Hazard control
