18. ELECTRICAL SYSTEM
18-20
Thermo unit
Remove the thermo unit.
Hang the thermo unit in an oil heater, heat the oil
and measure the resistance at each temperature.
Temperature 50°C 80°C 100°C 120°C
Standard (Ω)
134~149 47.5~57.0 26~29 14.8~17.2
Caution
Wear gloves and goggles when performing
this test.
Caution
Engine oil should be used as a heating
medium as the test temperature must be
higher than 100℃.
Contacting the container wall by the
thermometer and the thermo unit may result in
wrong readings.
Coolant Temperature Indicator Lamp
Disconnect the coolant temperature meter and
connect it to engine ground.
Turn on the main switch.
The indicator lamp of the fuel meter should be
lighting.
To this chapter contents
Thermo unit
Thermo unit
Indicator lam
