5. ENGINE REMOVAL
5-6
Remove the rear brake pedal.
Remove the coolant reserve tank.
Remove the front and rear side engine hanger
mounting nuts and bolts.
Remove left side engine hanger, and then remove
engine by left side.
Engine Installation
Check the bush of engine hanger parts for any
damage.
Install the engine in the reverse procedures of
removal.
Caution
Be careful when removing and installing the
engine.
Do not bend or twist the wires and tubes.
Cables wires have to be routed in accordance
with normal layout.
Engine hanger Bolt:
Torque value: 7.5~9.5kgf-m
3 bolts
2 bolts
Engine hanger
